EU22i

THE PORTABLE INDUSTRY FLAGSHIP

overview

EU22i

Our newest portable generator, the EU22i, is 10% more powerful than its predecessor, whilst remaining just as light and as quiet as before.

The number one portable generator, the EU22i, features a microcomputer-controlled sinewave inverter that guarantees commercial-quality electricity – making it ideal for use with frequency-sensitive electrical equipment such as laptops and home computers.

The EU22i features an eco-throttle adjusting the engine speed and only running at full capacity when required. This increases fuel economy and reduces noise.

It also features parallel connection compatibility. For additional power, you can link two Honda inverter generators in parallel operations with a simple connection cable.

CONTACT US

features
/10

SPECIFICATIONS

YOUR Generator IN DETAIL

EU22i
Engine
Product Code EU22ITU4
Generator Type
Mulitpole field rotation type (inverter)
Engine Commercial Grade GX120R
Displacement 121cc
Ignition System Transistor
Oil Alert Yes
Starting System Recoil
Stopping System
Ignition primary circuit ground
Fuel Unleaded
Fuel usage 1.14 litres/hr approx.
Fuel Tank Capacity 3.6 litres
Continuous Operating Hours 8.1 hours - with eco-throttle switched on at 1/4 output
Auto Choke No
Dimensions
Length 511mm
Height 425mm
Width 290mm
Weight 21kg
Output
Maximum AC Output 2200VA / 2200W
Rated AC Output 1800VA / 1800W
DC Output 8.3A
Rated Voltage 240V
Rated Frequency 50Hz
AC Circuit Breaker Yes
DC Circuit Breaker Yes
Operating Noise Level (At 7m)
53dB(A)* at 7m  - with eco-throttle switched on at 1/4 output
Features
Fuel Off feature
Yes - allows you to idle unit to use up fuel to help with storage eliminating stale fuel in fuel lines
Battery Charging Yes
Volt metre No
Auto Throttle Eco throttle
Fuel Guage No
Pilot Lamp Yes
Air Cleaner
Dual element type
Large Capacity Air Cleaner Yes
Large Capacity Fuel Tank Yes
Large Capacity Muffler Yes
Parallel connection Optional cable required
