TRX420FM1

BUILT TOUGH FOR NZ FARMS

Patriot Red
Overview

TRX420FM1

One of Honda’s most loved ATVs, the TRX420FM1 sets the benchmark for rugged durability.  With a reliable and economical 420cc engine this 4WD manual makes easy work of hilly terrain. Throttle response and economy are helped by the latest version of Honda’s Programmed Fuel Injection (PGM-FI) system. The new TRX420FM1 has revised carry racks, and a new built in front storage component which is perfect for storing keys, a phone, or similar you need to keep safe. It’s equipped with a double-cradle steel frame designed for precise handling and a smooth ride without compromising strength, 170mm of travel in both the front and rear suspension systems ensures a plush and controlled ride, and new guards extending the full length of the lower suspension arms provide full coverage of the driveshaft and outboard CV joints which helps protect the running gear of the bike and further improves the durability of this model!

BOOK A TEST RIDE

GALLERY

2020 TRX420FM1

Specifications

YOUR BIKE IN DETAIL

2020 TRX420FM1
Engine
Engine Type Liquid cooled OHV longitudinally mounted single cylinder, 4 stroke
CC Rating 420cc
Bore and Stroke 86.5mm x 71.5mm
Ignition Full transistorised with electronic advance
Carburetion Programmed Fuel Injection(PGM-FI) - 34mm throttle body
Transmission
Starter Electric with auxiliary recoil standard
Final Drive Direct front and rear driveshafts with torque sensing front differential
Transmission Manual 5-speed with reverse
Wheels, Suspension & Brakes
Suspension Front Independent double wishbone; 170mm travel
Suspension Rear Swing arm with single shock; 170mm travel
Brakes Front Dual hydraulic - 190mm discs
Brakes Rear Single sealed - 160mm mechanical drum
Tyres Front 24 x 8 - 12
Tyres Rear 24 x 10 - 11
Dimensions & Weight
Wheelbase 1,269mm
Seat Height 854mm
GroundClearance 181mm
Kerb Weight 280kg
Fuel Capacity 14.7litres including 4.9litres reserve
Dimensions 2,104mm(L) x 1,205mm(W) x 1,174mm(H)
Carrier Capacity 30kg Front rack - 60kg Rear rack
Towing Capacity 385kg
